Technical Data

Distance measurement
Precision (typical)*
Measurement range
(inside) **
Angle measurement
Measuring range
Resolution
Precision
Laser class
Laser wavelength
Strahldivergenz
Operating conditions
Storage conditions
Radio module
operating data
Automatic switch-off
Power supply
Dimensions (W x H x D)
Weight
* measuring distance up to 10 m with strongly reflective target surface
and at room temperature. The measurement deviation may increase by
± 0.2 mm/m for greater distances and under unfavourable measuring
conditions such as strong sunlight or weakly reflective target surfaces.
** at max. 5000 lux
EU directives and disposal
This device complies with all necessary standards
for the free movement of goods within the EU.
This product is an electric device and must be
collected separately for disposal according to
the European Directive on waste electrical and
electronic equipment.
Further safety and supplementary notices at:
http://laserliner.com/info?an=ACZ
LaserRange-Master T4 Pro
(Subject to technical changes without notice. 19W43)
± 2 mm
0.2 m - 40 m
± 90°
0.1°
0.1°
2 / < 1 mW
(EN 60825-1:2014/AC:2017/AC:2017)
650 nm
< 1.5 mrad
0°C ... 40°C, max. humidity 85% rH,
no condensation, max. working altitude
2000 m above sea level
-20°C ... 70°C, max. humidity 80% rH
Bluetooth LE 4.x interface;
Frequency band: ISM band
2400–2483.5 MHz, 40 channels;
Transmission power: max. 10 mW;
Bandwidth: 2 MHz; Bit rate:
1 Mbit/s; Modulation: GFSK/FHSS
Dynamic depending on measuring mode:
Laser: 30 s - 5 min
Device: 3 min - 8 min
2 x 1,5V LR03 (AAA)
23 x 100 x 35 mm
82 g (incl. batteries)
