INSTALLING THE REMOTE CONTROL WALL BRACKET

This product must not be installed at a height of more than 2 m.
As per the figure:
1.
Remove the protective film from the adhesive on the back of the wall bracket.
2. Fasten the wall bracket to a flat, clean and dry surface and press to ensure optimum bonding.
3.
Mount the remote control on its bracket.
1 2
▶ SITUO io
Frequency band and maximum
▶ SITUO RTS
Frequency band and maximum
EN - Installation and operating manual 1-channel - 5-channel variation remote controls - SOMFY
3
Radio frequency 868.95 MHz, io-homecontrol®
power used
Operating temperature 0°C to + 48°C
Power supply 1 type CR2430 battery, 3 V
Radio frequency 433.42 MHz, RTS
power used
Operating temperature 0°C to + 50°C
Power supply 1 type CR2430 battery, 3 V

TECHNICAL DATA

868.700 MHz - 869.200 MHz e.r.p. < 25 mW
433.050 MHz - 434.790 MHz e.r.p. < 10 mW
