| INSTALLING THE TURNTABLE

PLATTER
1
Remove the cap from the center of the
turntable.
2
Insert the ball bearing into the bearing
housing of the turntable taking care to
centre it on the bottom seat.
3
Add oil to spindle as shown in figure.
4
Insert the spindle into the bearing
housing.
2 3
drops drops
Ball bearing
5
Position the platter on the spindle.
6
Tighten the spindle tip onto the spindle
to lock the platter in place.
*PLEASE NOTE: the bearing housing is already
installed in the plinth of the turntable. Do not
remove it.
Bearing
housing
6
EN
DE
Platter
spindle
tip
Platter
Platter
spindle
IT
