Component Overview / Standard Delivery - Metabo BASIC 330 SILENT Originalbetriebsanleitung

Operating Instructions

1. Component Overview / Standard Delivery

12
11
10
9
1 Sound insulation hood
(encapsulates the pump)
2 Oil dip stick
3 Safety valve
4 Pressure vessel
5 Condensate drain cock
6 Compressed air outlet
(quick coupler)
7 Filter/Regulator unit
8 Condensate drain cock, filter/
regulator unit
9 Regulated pressure gauge
10 Tank pressure gauge
11 On/Off switch
12 Pressure regulator
ENGLISH
1
8
2
7
6
ENGLISH
3
4
5
9
