PRODUCT
DESCRIPTION
1
USB-C port
2
Charging slot
3
Indicator LED
DESKTOP CHARGER OPERATION
Connect the i.safe PROTECTOR USB cable on
Desktop Charger IS-DCTH1.1.
Connect the other end of the i.safe PROTECTOR USB cable to the power
supply adapter. Insert the power supply adapter into an AC power socket.
The Desktop Charger IS-DCTH1.1 is equipped with an indicator LED.
The following colors are used:
GREEN Standby or end of charge
RED Charging
To charge the IS530.x, put the IS-TH1xx.x connected with the phone into
the Desktop Charger IS-DCTH1.1.
When the battery is fully charged, the indicator LED of the Desktop Charger
IS-DCTH1.1 is switching to green.
WARNING
The phone may only be charged at ambient temperatures in a range from
+5 °C to +35 °C. Please do not use charging equipment if the temperature
exceeds this range. Only use the i.safe PROTECTOR USB cable to connect to
the Desktop Charger.
Using another cable may cause danger and will void the warranty of the
phone and the Desktop Charger.
the rear side
of the
EN
7
