Aufbau Peer L/XL
DE
Im eingebauten Zustand sieht das Ganze
wie in Bild 18 aus.
Die Beine werden am besten abgewinkelt
indem sie an der Knickstelle erhitzt, und
dann 180° umgebogen und gehalten
werden.
(A)
Beachte, dass das Knie-
gelenk nicht mittig im Schlauch sitzt,
sondern deutlich zum Pilotenkörper
hin versetzt, weil zum einen ein Teil
des Beines am Piloten angeformt ist
und zum anderen viel Bein im Schuh
verschwindet.
EN
Once installed it should look like Fig. 18.
The best way to bend the legs is to
carefuly use a heat gun to apply heat at
the point where you want to bend them,
then bend 180 and hold.
(A)
Note that
the knee joint is not in the middle of the
tube, but significantly offset towards the
pilots body. This is due to parts of the
legs being moulded to the pilot's body
and on the other end a significant part of
the leg "disappearing" in the boot.
Assembly Peer L/XL
A
18
19
31
