3. Layout & Connectors

3.1 Layout

Front:
5V Connector for
included external
Power Supply
Downstream A-Port
Back:

3.2 Connectors

5V Connector:
© Copyright 2021 by EXSYS Vertriebs GmbH. All Rights Reserved
Power LED
1x USB 2.0
ATTENTION!!!
Use only with Power Supply which is included in delivery!
2x USB 3.2 Gen 1
Downstream A-Port
1x USB 3.2 Gen 1
Upstream B-Port
9
English
1x USB 3.2 Gen 1
Downstream C-Port
