1. Description

The EX-1182VIS-2 is a plug & play high-speed USB 3.2 Gen 1 hub for 4 USB devices. The EX-
1182VIS-2 is equipped with two USB 3.2 Gen 1 A-Ports, one USB 3.2 Gen 1 C-Port and one USB
2.0 A-Port for devices and one USB 3.2 Gen 1 B-Port for connection to the PC. It supports all USB
connections from 1.1 to 3.2. All ports can fix with screw lock. Via a external power supply it is pos-
sible to provide a maximum of 1,5A on each USB 3.2 Gen 1 port and 500mA on the USB 2.0 port.
The EX-1182VIS-2 design fully utilize the Genesys chipset, which represents the latest in Super-
Speed USB interface technology. It uses data transfer rates up to 5Gbit/s. It provides a secure and
very high data transfer on each single USB 3.2 Gen 1 port. The EX-1182VIS-2 support self pow-
ered and bus powered mode. In addition the EX-1182VIS-2 is equipped with an 15KV ESD Surge
Protection an 3KV Optical Isolation. The EX-1182VIS-2 can be easily installed on the wall by using
the included wall mounting kit. The DIN-Rail kit for installation in a 19'' Rack is also included in the
scope of delivery. The DIN-Rail kit is screwed onto the underside of the wall mounting kit with four
screws.
Features:
•
Compatible for USB 1.1, 2.0, 3.0, 3.1 & 3.2
•
Up to 5Gbit/s
•
All operating systems are supported
•
All ports are screw lock
•
15KV ESD Surge Protection & 3KV Optical Isolation
•
Certificate for

2. Extent of Delivery

Before connecting the EX-1182VIS-2 to your PC, please check the contents of the delivery first:
•
EX-1182VIS-2
•
Power Supply (5V/4A)
•
USB 3.2 Gen 1 Cable (screw lock) (EX-K1581V)
•
DIN-Rail Kit (EX-6095)
•
Wall Mounting Kit
•
Manual
