Dokumentation, ohne vorherige Mitteilung. Bewahren Sie das Handbuch für die zukünftige Verwen- dung auf. Die hierin stehenden Anweisungen sind Teil des Produkts Konformitätserklärung Details finden Sie unter www.2VV.cz 2VV. Creating innovative solutions for you and your business since 1995.
Seite 3
Wenn die Einheit bei Temperaturen von weniger als 0°C • nach dem Entpacken transportiert wurde, lassen Sie die- se in Betriebsbedingungen für mindestens zwei Stunden M6x20 ohne Aktivierung, um die Innentemperatur zu kompensie- ren. VCV-xxW-SS 2VV. Creating innovative solutions for you and your business since 1995.
Seite 4
3. HAUPTKOMPONENTEN Abdeckungen des Ankerstativs Verrieglungsbolzen Serviceabdeckung Obere Abdeckung Ankerstativ - Teil 1 Ankerstativ - Teil 2 Abgasgitter 4. ABMESSUNGEN Abmessungen des Ankerstativs (mm) Abmessungen des Luftschleiers (mm) 2VV. Creating innovative solutions for you and your business since 1995.
Seite 5
VCV-B-25W 4350 41,5 46,5 bei Wassertemperaturabsenkung 90/70 °C VCV-B-25W 4350 50,1 Temperatur der angesaugten Luft +18°C Die anderen technischen Parameter sind im entsprechenden technischen Blatt des Produkts zu finden 2VV. Creating innovative solutions for you and your business since 1995.
100 mm 100 mm 100 mm (VCV-B-25W,S) MATERIAL 100 mm 100 mm MATERIAL MATERIAL 200 mm 500 mm 100 mm 100 mm 100 mm 100 mm 100 mm 100 mm 2VV. Creating innovative solutions for you and your business since 1995.
Seite 7
Neprodleně po nasunutí vzduchové clo- 4 x M5 4ks šroubů M8. (součást dodávky) ny do montážní polohy zajistěte kotvící podstavec Část 1 s Částí 2 pomocí 4ks šroubů M8. (součást dodávky) 2VV. Creating innovative solutions for you and your business since 1995.
Seite 8
• Detailní popis regulace vodního výměníku tří- normy a předpisy dané země. cestným ventilem (ZV-3) včetně jeho zapoje- ní naleznete v návodu k třícestnému ventilu ZV-3. 2VV. Creating innovative solutions for you and your business since 1995.
Seite 9
Firma angeschlossen werden, die das System ge- liefert hat. Minimale Kabelabmessungen: Kabel [Stk x mm2] VCV-B-25S 3 x 1.5 VCV-B-25E 5 x 6 VCV-B-25F 5 x 10 VCV-B-25W 3 x 1.5 2VV. Creating innovative solutions for you and your business since 1995.
KONTAKT 7.2 NASTAVTE SMĚR Adresa VYFUKOVANÉHO VZDUCHU 2VV, s.r.o., 2VV. Creating innovative solutions for you and your business since 1995. Poděbradská 289, Nastavení provedete vychýlením lamel v poža- 530 09 Pardubice, dovaném směru výfuku vzduchové clony. Česká republika...
überhitzt, muss die Ursache fest- gestellt und beseitigt werden. Wenn die Ursache irgendein interner Fehler • im Luftschleier ist, müssen Sie sich unbedingt an den zuständigen autorisierten Kundendi- enst wenden. 2VV. Creating innovative solutions for you and your business since 1995.
Seite 12
10. ELEKTROSCHEMAS Air Genio COMFORT MASTER + VCV-B-25E-CO-x-x 2VV. Creating innovative solutions for you and your business since 1995.
Seite 13
10. ELEKTROSCHEMAS Air Genio COMFORT SLAVE + VCV-B-25E-CS-x-x 2VV. Creating innovative solutions for you and your business since 1995.
Seite 14
10. ELEKTROSCHEMAS Air Genio COMFORT MASTER + VCV-B-25F-CO-x-x 2VV. Creating innovative solutions for you and your business since 1995.
Seite 15
10. ELEKTROSCHEMAS Air Genio COMFORT SLAVE + VCV-B-25F-CS-x-x 2VV. Creating innovative solutions for you and your business since 1995.
Seite 16
10. ELEKTROSCHEMAS Air Genio COMFORT MASTER + VCV-B-25W-CO-x-x 2VV. Creating innovative solutions for you and your business since 1995.
Seite 17
10. ELEKTROSCHEMAS Air Genio COMFORT SLAVE + VCV-B-25W-CS-x-x 2VV. Creating innovative solutions for you and your business since 1995.
Seite 18
10. ELEKTROSCHEMAS Air Genio COMFORT MASTER + VCV-B-25S-CO-x-x 2VV. Creating innovative solutions for you and your business since 1995.
Seite 19
10. ELEKTROSCHEMAS Air Genio COMFORT SLAVE + VCV-B-25S-CS-x-x 2VV. Creating innovative solutions for you and your business since 1995.
Seite 20
10. ELEKTROSCHEMAS Air Genio SUPERIOR MASTER + VCV-B-25W-SU-x-x 2VV. Creating innovative solutions for you and your business since 1995.
Seite 21
10. ELEKTROSCHEMAS Air GenioSUPERIOR SLAVE + VCV-B-25W-SS-x-x 2VV. Creating innovative solutions for you and your business since 1995.
Seite 22
10. ELEKTROSCHEMAS Air Genio SUPERIOR MASTER + VCV-B-25S-SU-x-x 2VV. Creating innovative solutions for you and your business since 1995.
Seite 23
10. ELEKTROSCHEMAS Air GenioSUPERIOR SLAVE + VCV-B-25S-SS-x-x 2VV. Creating innovative solutions for you and your business since 1995.
Seite 24
Bei Unklarheiten und Zweifeln können Sie sich gerne an unseren Service oder unseren technischen Kunden- dienst wenden. KONTAKT Adresse: 2VV, s.r.o., Fáblovka 568, 533 52 Pardubice, Česká republika Internet : http://www.2vv.cz/ 2VV. Creating innovative solutions for you and your business since 1995.
