Dokumentation, ohne vorherige Mitteilung. Bewahren Sie das Handbuch für die zukünftige Verwen- dung auf. Die hierin stehenden Anweisungen sind Teil des Produkts Konformitätserklärung Details finden Sie unter www.2VV.cz 2VV. Creating innovative solutions for you and your business since 1995.
Seite 3
Entsorgung oder das Recycling ren. der Verpackungsmaterialien sicher. 3. HAUPTKOMPONENTEN Halterungen (2Stck) Planenaufbau Bereich zur Verbindung des Steuermoduls Saugdeckel Verbindung des Wassertauschers (nur Wassernodell) Seitendeckel Anschlusskasten für Hauptstromanschluss. 2VV. Creating innovative solutions for you and your business since 1995.
Seite 4
27,6 VCES2B-150-V VCES2C-150-V 32,9 39,3 VCES2B-200-V VCES2C-200-V 40,1 47,6 VCES2B-250-V VCES2C-250-V 47,4 55,3 VCES2B-100-S VCES2C-100-S 24,8 26,3 VCES2B-150-S VCES2C-150-S 31,3 35,7 VCES2B-200-S 38,3 VCES2C-200-S 45,8 VCES2B-250-S 45,1 VCES2C-250-S 53,1 2VV. Creating innovative solutions for you and your business since 1995.
VCES2C-100-S 50/60 VCES2C-150-S 50/60 VCES2C-200-S 50/60 VCES2C-250-S 50/60 * Ansauglufttemperatur +18°C bei maximaler Heizungsleistung und Lüftergeschwindigkeit. Die anderen technischen Parameter sind im entsprechenden technischen Blatt des Produkts zu finden 2VV. Creating innovative solutions for you and your business since 1995.
Halterungen gehalten haben und hängen Sie den Vorhang an ihnen auf. Überprüfen Sie, dass der Vor- hang richtig befestigt ist, um ein Herunterfallen zu ver- hindern 2VV. Creating innovative solutions for you and your business since 1995.
Seite 7
2. Befestigung am Vorhang 4 6mm Anker (nicht mitgeliefert) 4 M6 Gewindestangen (nicht mitgeliefert) 8 M6 Muttern (nicht mitgeliefert) M10 Schlüssel (nicht mitgeliefert) 30mm von den Gewindestangen hängend 10mm 2VV. Creating innovative solutions for you and your business since 1995.
Seite 8
Motors befestigt ist 6.4.2 Installation des Steuermoduls (Nicht mitgeliefert) 1) stecken Sie das Modul in die Einheit ein Verspannen der Klemmleiste mit Siko-Zangen: VORSICHT! Siko-Zangen werden nicht mitgeliefert 2VV. Creating innovative solutions for you and your business since 1995.
Seite 9
Zangen, um Schäden zu verhindern (siehe Die Versorgung muss vom entsprechenden Entwickler Abbildung) bestimmt werden und muss mit den anwendbaren Vor- schriften übereinstimmen und den Strom eines Installati- onsparameters des Luftvorhangs berücksichtigen 2VV. Creating innovative solutions for you and your business since 1995.
Seite 10
Leiten Sie die Abluft in die gewünschte Richtung während der Installation der Einheit um. Die Abluft des Essensse Luft- vorhangs kann Luft bei einem maximalen Winkel von 15°C blasen. 15° 2VV. Creating innovative solutions for you and your business since 1995.
Bewahren Sie unbrauchbare Teile des Produkt an einer kontrollierten Mülldeponie auf. Bei der Entsorgung von Materialien ist es notwendig, die entsprechenden nationalen Vorschriften der Abfallent- sorgung zu beachten. 2VV. Creating innovative solutions for you and your business since 1995.
Seite 12
10. SCHALTPLÄNE VSES2B100-E1AC-ZP-xxx VSES2B100-V1,S0AC-ZP-xxx 2VV. Creating innovative solutions for you and your business since 1995.
Seite 13
10. SCHALTPLÄNE VSES2B150-E1AC-ZP-xxx VSES2B150-V1,S0AC-ZP-xxx 2VV. Creating innovative solutions for you and your business since 1995.
Seite 14
10. SCHALTPLÄNE VSES2B200-E1AC-ZP-xxx VSES2B200-V1,S0AC-ZP-xxx 2VV. Creating innovative solutions for you and your business since 1995.
Seite 15
10. SCHALTPLÄNE VSES2B250-E1AC-ZP-xxx VSES2B250-V1,S0AC-ZP-xxx 2VV. Creating innovative solutions for you and your business since 1995.
Seite 16
10. SCHALTPLÄNE VSES2C100-E1AC-ZP-xxx VSES2C100-V1,S0AC-ZP-xxx 2VV. Creating innovative solutions for you and your business since 1995.
Seite 17
10. SCHALTPLÄNE VSES2C150-E1AC-ZP-xxx VSES2C150-V1,S0AC-ZP-xxx 2VV. Creating innovative solutions for you and your business since 1995.
Seite 18
10. SCHALTPLÄNE VSES2C200-E1AC-ZP-xxx VSES2C200-V1,S0AC-ZP-xxx 2VV. Creating innovative solutions for you and your business since 1995.
Seite 19
10. SCHALTPLÄNE VSES2C250-E1AC-ZP-xxx VSES2C250-V1,S0AC-ZP-xxx 2VV. Creating innovative solutions for you and your business since 1995.
Seite 20
Lesen Sie nach der Installation des Luftvorhangs sorgfältig das Handbuch für den entsprechenden Regler. Bei Zweifeln oder Fragen zweifeln Sie nicht unsere Verkaufsabteilung oder den technischen Support zu kontaktieren. KONTAKT Adresse 2VV, s.r.o., Fáblovka 568, 533 52 Pardubice, Česká republika http://www.2vv.cz/ 2VV. Creating innovative solutions for you and your business since 1995.
