RD5000WLT transmitter
1
Transmitter front panel
1.
On/Off key.
2.
On/Off LED.
3.
Alkaline battery warning LED: Flashes when batteries are in use and are low.
.
Lithium Ion rechargeable battery warning LED: Flashes when batteries are in use
and are low.
5.
Accessory socket for direct connection lead, signal clamp and charging internal
Lithium Ion rechargeable battery pack.
Transmitter rear panel
.
Fuse holder.
Note: The transmitter is supplied with a non-fitted fuse for shipping and before
use this will have to be inserted into the fuse holder.
.
Alkaline battery compartment: Requires off D-Cells.
The RD5000 transmitter incorporates a rechargeable Lithium Ion battery pack and
this is the intended primary power source for the transmitter. When the Lithium Ion
low battery level LED illuminates the user should either recharge the battery pack
using the Radiodetection supplied charger or alternatively fit off alkaline batteries.
If alkaline batteries are fitted to the transmitter, these will be detected automatically
and the transmitter will take its power from the alkaline batteries. When the alkaline
batteries are low the alkaline low battery level LED will illuminate.
7
6
2
3 4
5
