6.1 Dismount tyre from the rim
Slowly release the air from the tyre.
Remove all balance weights and other foreign
materials from the rim.
Lubricate the tyre bead with suitable lubricant or
soap suds, before you separate the tyre from the
rim with the bead-breaker to prevent the tyre
bead from damage.
Place the tyre to the tyre positioning plate
(20), so that the bead-breaker (19) edge is
max. 1cm far from the rim edge.
Keep hands/feet of danger area of bead-
breaker!
Operate foot pedal (1), the bead-breaker will
press the tyre off the rim.
Remove these steps several times until the
tyre is separated from the rim entirely.
Place the tyre onto the tyre disc (5).
ATTENTION: for
place the rims so that the flat side shows
upwards.
Operate foot pedal (2) for clamping and cen-
tering the rim.
Attention: For sensible rims use the four pro-
vided plastic clamps.
If you wish to clamp your rim from inside to
outside, first operate pedal (2) until jaws are
centered in the middle, place the rim onto
the tyre disc and operate the pedal (2)
again.
Swing the swing arm (9) into working posi-
tion over the rim edge, press the mounting
bar downwards until the mounting head (7)
clears the rim edge 1-2mm
Fix the head in this position with the height
fixation lever (11) and fix the swing arm po-
sition as well.
See figure D:
Slip the outer tyre bead with the help of the
provided mounting bar over the mounting
head (7).
Operate the foot pedal (3) to move the tyre
disc (5) until the outer tyre bead is slipped
over the rim edge entirely. Always check the
postion of the valve during rotation to avoid
damage!
See figure E:
Remove the air tube first, if present.
Slip with the mounting lever the lower tyre
bead over the mounting head.
All manuals and user guides at all-guides.com
asymmetric lowbed-rims
Operate the foot lever (3) to pull the entire
lower tyre bead over the rim edge.
6.2 Mount tyre onto a rim
Check whether tyre and rim match regarding
technical dimensions, especially width and
diameter!
If using a new rim, clamp it as described, if
you mount a new tyre on a already clamped
rim – let it be clamped.
Lubricate the tyre bead with suitable lubri-
cant!
See Figure F:
Place the tyre onto the rim in a way, that the
left side is higher than the right side and
bring the mounting head into position as
shown in the figure.
Position the tyre in a way that the tyre bead
is over the left (see Fig. F 1) but is simulta-
neously under the right side (see Fig. F 2) of
the mounting head.
Operate foot pedal (1), the inner tyre bead
gets pulled under the rim edge.
If required, insert now the tyre-tube in a way
that it will not constrain the mounting.
See Figure G:
Perform the mounting similarily.
But when having the last 10-15cm being pulled
under the rim edge take special care that the
tyre bead gets not damaged. Stop the tyre disc if
required and reverse if necessary. Try to easy
the pull down by pressing onto the tyre on the
other side already being pulled under the rim.
