e. Program the ESC with the Set Button
The following is a flowchart sample for
programming the Dragster micro X-18 Brushless
controller.
Turn off the ESC
Turn off the transmitter
Hold the set key,
switch on the ESC
Hold on the button
Red LED flashes
Green LED flashes
for 1 time
Hold SET key for 3 seconds
Green LED flashes
for 2 times
Hold SET key for 3 seconds
Green LED flashes
for 3 times
Hold SET key for 3 seconds
Green LED flashes
for 4 times
Green LED flashes
for 5 times
Note: Note:
In the program process, when the LED is flashing, the motor will emit
"Beep" tone at the same time.
Enter the corresponding
programmable adjustment,
the red LED flashes for several
times, the times present the
current value of this item.
Enter the 1st adjustment
"Running Mode"
Release
SET key
Enter the 2nd adjustment
"Drag Brake Force" in
neutral position
Release
SET key
Enter the 3rd adjustment
"Low Voltage Cut-Off"
Release
SET key
Enter the 4th adjustment
"Accelleration mode"
Release
SET key
Enter the 5th adjustment
„Max. braking force"
Release
SET key
CARSON X-18 Chassis 500404046 + 500404047
Flowchart: Program the ESC with the SET key.
Press the SET key to choose
the programmable value, the
RED LED flashes for several
times, the times
present the serial number of
the value you are
choosing.
✼
✼ = 3 sec
Red LED flashes for 1 time to choose
"Forward with brake"
Red LED flashes for 2 times to choose
"Forward/reverse with brake"
Red LED flashes for 3 times to choose
Press
"Forward and reverse"
SET key
Red LED flashes for 1 time, choose "0%"
Red LED flashes for 2 times, choose "5%"
Red LED flashes for 3 times, choose "10%"
Red LED flashes for 4 times, choose "20%"
Red LED flashes for 5 times, choose "40%"
Press
SET key Red LED flashes for 6 times, choose "60%"
Red LED flashes for 7 times, choose "80%"
Red LED flashes for 8 times, choose "100%"
Red LED flashes for 1 time, choose "None"
Red LED flashes for 2 times, choose "2.6 V"
Red LED flashes for 3 times, choose "2.8 V"
Press
Red LED flashes for 4 times, choose "3.0 V"
SET key
Red LED flashes for 5 times, choose "3.2 V"
Red LED flashes for 6 times, choose "3.4 V"
Red LED flashes for 1 time, choose "Level 1"
Red LED flashes for 2 times, choose "Level 2"
Red LED flashes for 3 times, choose "Level 3"
Red LED flashes for 4 times, choose "Level 4"
Press
SET key
Red LED flashes for 1 time, choose "25%"
Red LED flashes for 2 times, choose "50%"
Press
Red LED flashes for 3 times, choose "75%"
SET key
Red LED flashes for 4 times, choose "100%"
Attenion
