You have just purchased a wood burning stove from our range. We would first like to congratulate you on your choice. This appliance
has been carefully designed. In order to make the most of all its advantages, we would advise you to request the services of one of our
specialists. This will ensure that the installation is made in accordance with good practices and will guarantee the best operating and
safety conditions, bearing all the responsibility for the final installation.
Before lighting the fire for the first time, please read these installation and operating manual carefully. Retain the manual and warranty
(which indicates the model and serial No.). The person performing the installation work shall be fully liable for any failure to comply with
the instructions set out in these two documents.
Your stove has a "good draw" but you do not know its draught value. The chimney draught is measured in Pascal (Pa). The
inserts, fireboxes and stoves have been designed, optimised and manufactured in accordance with standards NF EN 13229 (or
NF EN 13240) to operate connected to a chimney with a draught of 12 Pa. It frequently happens (in more than one in two
chimneys) that the draught is far too high (over 20 Pa) due to the fact that the chimney is either too high or due to the flue
liner. In this case, the appliances will operate in abnormal conditions which may lead to:
- Excessive wood consumption: this can be three times as much as an appliance with a draught of 12 Pa.
- A fire that "does not last" and burns too quickly while producing insufficient heat.
- A quick and inevitable deterioration of the appliance (cracks in the cast iron panels or in the refractory bricks)
- A voided warranty.
To avoid all these problems, there is only one solution!
Get a professional to check the chimney draught (with the appliance operating) and, if it is above 20 Pa, then install a damper
or an adaptor at the flue connection.

1. TECHNICAL SPECIFICATIONS

STOVE
Stove category
Rated heat output (1)
Operating mode
Connection type
Mean flue gas temperature
Efficiency
Seasonal efficiency
CO concentration (13% 02)
CO2 concentration (13% 02)
Dust concentration (13% 02)
VOC
NOX
Fuel
Log size
Nominal load per hour approx.
Refuelling
Prohibited fuels
Approx. flue gas mass flow
Flue pipe nominal diameter
Characteristics of the flue pipe
Chimney flue minimum dimensions
Ø min. flue lining or insulated metal duct
Minimum height of the pipe above the
appliance
Ventilation of the room
Draught (10 Pa = 1 mm CE)
Nominal efficiency
Performance in slumber mode (min. permitted)
Max. permitted
Net / gross weight
Nameplate
Accessories supplied
Insulating glove, Upper damper (air)
Option available
-
(1) Rated power in operation with the door closed, wood fuel, according to the tests performed under standard EN 13240.
(2) DTU 24.1 covering flue ducting, DTU 24.2 covering chimneys equipped with a closed stove; NIF EN 13240 covering solid fuel burning
stoves. (Available at AFNOR).
- IMPORTANT -

- IMPORTANT ASSEMBLY INFORMATION -

CHLOE / CHLOE PIED
Intermittent
6 kW
Only with the door closed
Horizontal or vertical
309 °C
80.9 %
70.9%
0.1 %
8.8 %
3
39.8 mg/Nm
3
53.1 mg/Nm
3
76.2 mg/Nm
Wood
horizontally 25 cm / vertically 33 cm
2.2 kg/h
1 h
All the rest, including coal and its
derivatives
7.4 g/s
150 mm
20 x 20 cm
150 mm
4 m
1 dm²
12 Pa ± 2 Pa
6 Pa ± 1 Pa
20 Pa
85 kg / 105 kg
On the rear of the appliance
