Cleaning The Protective Motor Filter - Dirt Devil Infinity Mcc Bedienungsanleitung

4 Filters
4.2 Cleaning the protective
motor filter
1
b
1. Switch the appliance off and observe the instructions
under
power cable".
2. Remove the dust container,
the dust container", Steps 1 - 2.
3. Release the filter cover (Fig. 24/1) and remove it.
1
4. Remove the protective motor filter together with the
holder at the lip provided for this purpose below right
(Fig. 25).
5. Hold the protective motor filter together with the holder
over a dustbin. Only then should you separate both
Fig. 24
parts from each other. For a rough clean, gently knock
both parts over a dustbin (Fig. 26).
ATTENTION:
The protective motor filter is not suitable for the
dishwasher.
NOTE:
If the protective motor filter is very dirty, rinse it
Fig. 25
thoroughly with a shower head (Fig. 27). Do not use any
brushes for this.
Then leave the filter to dry (approx. 15 hours at room
temperature). Only use it again when it is completely dry.
If the dirt cannot be removed, insert a new protective
motor filter (order number:
6. Insert the dry protective motor filter back into its holder.
7. Place protective motor filter together with the holder
Fig. 26
back into its receptacle.
8. Replace the filter cover by hooking it precisely from
above first (Fig. 28/a). Then engage the lock by
pressing it (Fig. 28/b) until it audibly clicks into place.
NOTE:
The filter cover must be inserted correctly for the dust
container to fit into its mounting bracket. Pressing firmly
will not help if the cover has not been positioned
precisely (Fig. 28/a)!
Fig. 27
9. Place the dust container onto the cylinder vacuum
cleaner. Press the dust container firmly into its
mounting bracket until it audibly clicks into place.
10. Check whether the dust container is securely seated.
a
NOTE:
It may be necessary to push a bit harder. To make it
easier, you can hold the release button pressed when
inserting the dust container.
Fig. 28
Chapter 3.2, "Switching off and retracting the
Chapter 8, "Spare parts").
Chapter 3.4, "Emptying
31
