SETUP:
SETUP:
NOTE:
See chapter 1 for FEED key functions.
Q
Q
1
1
PRINTER TYPE .............................Q1
PRINTING HEAD TYPE .................C72
INTERFACE ...................................RS232
PROGRAM MEMORY TEST..........OK
STATIC RAM TEST........................OK
EEPROM TEST..............................OK
CUTTER TEST...............................OK
HEAD VOLTAGE [V]
HEAD TEMPERATURE [°C]
POWER ON COUNTER
PAPER PRINTED [cm]
CUT COUNTER
RS232 Baud Rate .....................:
RS232 Data Length ...................:
RS232 Parity .............................:
RS232 Handshaking .................:
Busy Condition ..........................:
USB Address Number ...............:
Autofeed ....................................:
Print Mode .................................:
Chars / inch ...............................:
Speed / Quality..........................:
PaperEnd Buffer Clear ..............:
Print Density..............................:
[PUSH]
[FAST PUSH] key to skip setup
1 Go into SETUP mode by starting to press the
GB
FEED Key before switch on the printer and going
on to press it for a few seconds after the printer
power up.
2 The printer should print all list of the parameters:
•
RS232 Baud Rate
D
19200
•
RS232 Data length
•
RS232 Parity
•
RS232 Handshaking
ware.
•
Busy condition
•
USB Address Number
•
Autofeed: CR disabled
•
Print mode: Normal
•
Chars/inch: A=11 B=15 cpi, A=15 B=20 cpi
•
Speed/Quality: Normal
•
PaperEnd Buffer Clear: Disabled, Enabled
•
Print Density: -50%, -37%, -25%, -12%, 0
,+12%, +25%,+37%, +50%.
Notes: The parameters indicates with a D symbol
are the default values.
(1)
Note
: Parameter valid only on serial printer.
Note
(2)
: This parameter is used to identify univocally
the USB printer by a numerical address code,
if on the PC are connected two printers that
are the same models, for example two Q1.
<27>
PRINTER SETUP
= 24,29
= 26
= 28
= 40
= 573
19200 bps
8 bits/chr
None
Xon/Xoff
RxFull
0
CR Disabled
Normal
A=15 B=20 cpi
Normal
Disabled
0%
key to enter setup
(1)
: 115200, 57600, 38400,
, 9600, 4800, 2400, 1200.
(1)
: 7, 8
D
bits/char.
(1)
: None
D
, even or odd.
(1)
: XON/XOFF
(1)
: OffLine/RxFull or RxFull
(2)
: 0.
D
or CR enabled.
D
or reverse.
D
or High Quality.
D
or Hard-
D
.
D
.
D
.
D
