3. Adjust and tighten both sides using the
adjusting screws (Figure 5, pos. 2).
4. Make sure the supports (Figure 5, pos. 1) are
pressed against the inside of the door.
When the mailbox flap goes inwards, make
sure only the handle (Figure 3, pos. 1) sticks
out from the mailbox.
5. Fix the main body and transit with the screws
(Figure 6, pos. 2) using a Philips screwdriver
(Figure 6, pos. 1).

Installation

CAUTION
Only suitable for mobile air conditioning systems with a cooling capacity of up
to 14,000 BTU / 4,100 watts.
CAUTION
Only suitable for an air conditioning hose with a diameter of
150 mm.
Two different air conditioning hoses can be installed to the Way-out:
•
With a click system, for a hose with a collar (Figure 7, pos. 1).
•
With a rotating system, for a hose without a collar (Figure 8, pos. 1).
Figure 5
Figure 6
11
