Electrical Connection (UK only)
IF THE MAINS LEAD OF THE APPLIANCE IS FITTED
WARNING - THIS APPLIANCE MUST BE
EARTHED
Fuse replacement
If the mains lead of this appliance is fitted
with a BS 1363A 13 amp fused plug, to
change a fuse in this type of plug use an
A. S. T. A. approved fuse to BS 1362 type
and proceed as follows:
1. Remove the fuse cover (A) and fuse (B)
2. Fit replacement 13A fuse into fuse cover
3. Refit both into plug.
IMPORTANT:
The fuse cover must be refitted when
changing a fuse and if the fuse cover is
lost the plug must not be used until a
correct replacement is fitted. Correct
replacements are identified by the colour
insert or the colour embossed in words on
the base of the plug. Replacement fuse
covers are available from your local
electrical store.
92
WITH A PLUG
CONNECTION TO A REWIREABLE
PLUG
If the fitted plug is not suitable for your
socket outlet, then it should be cut off and
disposed of in order to avoid a possible
shock hazard should it be inserted into a
13A socket elsewhere. A suitable
alternative plug should then be fitted to the
cable.
The wires in this mains lead are coloured
in accordance with the following code:
BLUE "NEUTRAL" ("N")
BROWN "LIVE" ("L")
GREEN AND YELLOW "EARTH" ("E")
1. The GREEN AND YELLOW wire must
be connected to the terminal in the plug
which is marked with the letter "E" or by
the Earth symbol
or green and yellow.
2. The BLUE wire must be connected to
the terminal which is marked with the letter
"N" or coloured black.
3. The BROWN wire must be connected
to the terminal which is marked with the
letter "L" or coloured red.
or coloured green
