4
DESCRIPTION OF THE APPLIANCE
4.1
GENERAL PARTS
Parts of the dishwasher*
1)
salt container
2)
rinse aid container
3)
drying ventilator
(if included)
4)
container for detergent
5)
data tag
6)
filters
7)
lower spray-rotor
8)
upper spray-rotor
9)
electric cable
10) water supply tube
11) water drainage tube
12) lower basket
13) upper basket
14) cutlery container
15) hook for door
closing mechanism
16) Drum handles
(if provided)
* Details may differ
depending on model and
market!
4.2
TECHNICAL DATA
capacity (standard settings): 12
pressure of water supply system
minimum pressure: 0.05 Mpa
maximum pressure: 1 Mpa
1 2 3 4 5 6 7 8 9 0
1 2 3 4 5 6 7 8 9 0
16
1 2 3 4 5 6 7 8 9 0
GB
1 2 3 4 5 6 7 8 9 0
1 2 3 4 5 6 7 8 9 0
1 2 3 4 5 6 7 8 9 0
1 2 3 4 5 6 7 8 9 0
13
16
1
14
16
5
3
12
0,05 - 1MPa
MAX .......W
........V.....Hz
Made in EU
15
4
2
6
Attention: the necessary characteristics
of the electric supply grid are indicated
on the data tag.
Model.
......................
....A
...................
1
8
9
10
7
11
14
12
