Maintenance; Warranty; Technical Information - DEFA MultiCharger 1x12A Gebrauchsanleitung

The charger is maintenance free. All batteries should be inspected monthly as a minimum to achieve the best possible safety. The
charging process is in such way that the batteries remain fully charged without further water consumption than normal evaporation.
The guarantee applies to faults in production and materials for 2 years from date of purchase. The customer must deliver the product
back to the place of purchase together with the receipt. The guarantee shall cease to apply if the charger is handled negligently, opened
or repaired by someone other than DEFA or an authorized representative of DEFA. DEFA has no other guarantee than this and will not
be responsible for other costs than those referred to, i.e. no possible additional costs. Neither is DEFA bound by any other guarantee.
Item number
Mains Voltage [VAC]
Temperature Range [ºC]
Charging Voltage* [VDC]
Maintenance [VDC]
Current Max. [A]
Battery Size Max. [Ah]
IP rating [IP]
Weight [kg]
Measure (H/W/D) [mm]
Acceptance
* Temperature-compensated approx 5,0 mV/

MAINTENANCE

WARRANTY

TECHNICAL INFORMATION

705200 (MultiCharger 1x12), 705400 (MarineCharger 1x12), 705600 (RescueCharger 1x12)
230
-35 +50
14,4
13,5
12
150
44
1
138x98x53
EN60335-1, EN60335-2-29, EN55014-1, EN55014-2, EN61003-3/2
C/cell. Ref. 25
o
C.
o
5
