The dairy/fruit cooling cabinet of your ARB Fridge Freezer is designed to maintain a
temperature that is warmer than the main cooling cabinet. This makes it an excellent
place to store selected items like dairy products, fruit, vegetables and chocolate.
B
A
*
The power LED i g een when the compres or is running. The power LED is orange when the s r
compressor i not running (eg. when the fridge freezer has reached its target temperatu e). s

5 INSTALLATION

5.1

General installation

The following points should be considered when choosing a location to install your
ARB Fridge Freezer.
A minimum clearance of 50 mm must be maintained on all sides of the fridge
freezer.
Whether the installation is permanent or temporary, the fridge freezer must be Whether the installation is permanent or temporary, the fridge freezer must be
attached to secure anchorage points. attached to secure anchorage points.
The ideal mounting position for the fridge freezer is on a flat, horizontal surface. If The ideal mounting position for the fridge freezer is on a flat, horizontal surface. If
the fridge freezer is subject to sideways angles (eg heal on a boat), it can the fridge freezer is subject to sideways angles (eg heal on a boat), it can
withstand a sideways angle of 30°. withstand a sideways angle of 30°.
Avoid placing the fridge freezer near sharp or hot objects. Avoid placing the fridge freezer near sharp or hot objects.
Avoid placing the fridge freezer near loose objects that could fall on the cabinet Avoid placing the fridge freezer near loose objects that could fall on the cabinet
and obstruct its operation. and obstruct its operation.
Never operate the fridge freezer near flammable liquids or vapours. Never operate the fridge freezer near flammable liquids or vapours.
Figure 4 - Control panel
C D
A. Power ON / OFF Button
B. Power Indication LED *
C. Error Indication LED
D. Function Button
E. Digital Temperature Display
F. Temperature Up Button
G. Temperature Down Button
E
(change setting up)
(change set ing down)
s
F G
t
r
