4 INTRODUCTION TO YOUR ARB FRIDGE FREEZER

The key components of your ARB Fridge Freezer are identified below in Figures 1 to 4.
Figure 1 – Front of fridge
1
2
3
4
5
16
17
18
19
20
21
1. Lid latch
2. Control panel
3. Front carry handle
4. Powdercoated zinc steel cabinet
5. Rubber feet x 4
6. Lid
7. Cabinet fuse
8. 100-240V AC power socket
9. 100-240V AC cable clip
10. Lid stop
11. Rear carry handle
5
6
7
8
9
Figure 3 – Interior cabinet
Figure 2 – Rear of fridge
12. Compliance plate and
serial number
13. Motor surround
14. 12/24V DC power socket
15. 12/24V DC cable clip
16. Reversible Basket
17. LED cabinet light
18. Drain plug
19. Removable basket divider
20. Main cooling cabinet
21. Dairy/Fruit cooling cabinet
