6.18 Replacing the light bulb

Your fridge freezer is equipped with a long life and low current draw LED light bulb.
Under typical operating conditions this bulb should not require replacement. In the
unlikely event that you need to replace the light bulb, please follow the procedure
outlined below.
CAUTION – Disconnect the fridge freezer from all power sources before
replacing the light bulb.
To replace the light bulb:
If the basket is fitted with its high side against the front of the fridge, it must be
removed to provide access to the light housing. Refer to section 6.12 for details.
Remove the transparent light housing from the internal case of the fridge freezer
as shown in Figure 17a. To do this, place your finger under the lip of the light
housing and pry it away from the internal case of the fridge freezer.
Replace the defective light bulb with a new bulb of the same rating as shown in
Figure 17b. Replacement bulbs can be purchase from your nearest ARB Fridge
Freezer service agent.
Ensure that the LEDs inside the bulb are facing the transparent face of the light
housing.
Test that the light functions correctly.
Refit the light housing into the cabinet of the fridge freezer.
Figure 17a
Light housing

6.19 Storing your fridge freezer

If you are storing your fridge freezer for an extended period of time, ARB makes the
following recommendations.
Switch the fridge freezer off and disconnect it from all sources of power.
Remove all items except the basket and basket divider from within the cabinet.
Leave the lid slightly open to allow airflow through the cabinet.
HINT - A soft piece of foam or rubber could be placed between the fridge
freezer cabinet and lid to ensure that the lid remains open. Care must be
taken to ensure that this temporary item does not damage the cabinet, lid or
lid seal.
Figure 17b
Light bulb
Bulb holder
