Making Use Of The Basket - ARB FRIDGE FREEZER Bedienungsanleitung

To change the battery protection level:
Turn the fridge freezer on.
Press three times to display current battery protection setting.
Press or
Medium (nEd) and Low (Lo).
After 5 to 6 seconds of inactivity, the display will flash twice and return to
displaying the current cabinet temperature.
High

6.12 Making use of the basket

Your ARB Fridge Freezer is supplied with a reversible wire basket that helps to protect
the internal walls of the fridge freezer cabinet. The basket can be installed with the high
side of the basket against the front of the fridge as shown in Figure 12a. This allows
long items to be laid across the top section of the fridge freezer cabinet. The basket can
be repositioned so that the high side of the basket is in the centre of the cabinet as
shown in Figure 12b. This provides a full height divider between the main cooling
cabinet and the dairy/fruit cabinet.
High side
of basket
T o remove the basket from the cabinet:
Lift the basket vertically out of the fridge freezer cabinet.
T o reinstall the basket into the cabinet:
Slide the basket down into the cabinet of the fridge freezer. The basket is correctly
positioned when its base is in contact with the base of the fridge freezer cabinet.
to change the battery protection voltage between High (HI),
Figure 12a
Medium
Figure 12b
High side
of basket
Low
18
