of this piece. To do this first attach the support cover L1
supplied with the equipment to the base of the machine
and fix it in place with the K screws (Fig. 19).
9. CONNECTING TO EXTERNAL ASPIRATION
To connect the machine to AS182K, AS282K aspirators or
any other external aspiration, the aspiration connector
6446073 (optional accessory) must be attached. Connect
the rubber nozzle to the machine's socket B1 (Fig. 10)
10. BRUSH AND COLLECTOR MAINTENANCE
Unplug the machine from the electrical
outlet before carrying out any maintenance.
Remove screws R (Fig. 16) holding the side covers T and
separate them.
Remove the brush-holder S (Fig. 17) with small screw-
driver V, using one of the brush-holder side tabs to
lever it out.
Push back the end of spring Q. Keep it in this position
to extract the brush and replace it with a new genuine
Wegoma by Virutex brush. Reinsert the brush-holder,
ensuring that it is firmly positioned in the casing and
that each of the brushes exerts a small amount of
pressure on the collector.
Reattach the covers "T" with the corresponding screws,
making sure that no wires get caught in the process.
It is advisable to allow the machine to run for 15 mi-
nutes in order to ensure that the brushes have properly
settled into place.
If the collector burns or juts out, it should be serviced
by a Wegoma by Virutex service technician.
Keep the cable and plug in good working condition.
11. ACCESSORIES AND TOOLS
Guides to copy with a template (see Fig. 18)
Reference For cutter size
2950104 6 mm
2950105 8 or 7.6
2950106 10 mm
2950107 12 mm
2950081 14 mm
2950108 16 mm
1222084 Chuck collet Ø 6 mm.
1222024 Chuck collet Ø 8 mm, supplied.
1222085 Chuck collet Ø 1/4"
1140087 90° trimming bit, supplied.
1140016 Straight bit D.18 mm, supplied.
Bits for several jobs: See page 29
6446073 Dust collector connection
Ø A Ø B
8 mm 10mm
10 12
12 14
14 16
16 18
18 20
Always use bits with the appropriate
shank diameter for the chuck collet and
tool speed to be used.
12. NOISE AND VIBRATION LEVEL
The noise and vibration levels of this device have been
measured in accordance with European standard EN
60745-2-17 and EN 60745-1 and serve as a basis for com-
parison with other machines with similar applications.
The indicated vibration level has been determined for
the device's main applications and may be used as an
initial value for evaluating the risk presented by expo-
sure to vibrations. However, vibrations may reach levels
that are quite different from the declared value under
other application conditions, with other tools or with
insufficient maintenance of the electrical device or its
accessories, reaching a much higher value as a result
of the work cycle or the manner in which the electrical
device is used.
Therefore, it is necessary to establish safety measures
to protect the user from the effects of vibrations, such
as maintaining both the device and its tools in perfect
condition and organising the duration of work cycles
(such as operating times when the machine is subjected
to loads, and operating times when working with no-load,
in effect, not in use, as reducing the latter may have a
considerable effect upon the overall exposure value).
13. WARRANTY
All Wegoma by Virutex power tools are guaranteed for
12 months from the date of purchase, excluding any
damage which is a result of incorrect use or of natural
wear and tear on the machine. All repairs should be
carried out by the official Wegoma by Virutex technical
assistance service.
14. RECYCLING ELECTRICAL EQUIPMENT
Never dispose of electrical equipment with domestic was-
te. Recycle equipment, accessories and packaging in ways
that minimise any adverse effect on the environment.
Comply with the current regulations in your country.
Applicable in the European Union and in European
countries with selective waste collection systems:
If this symbol appears on the product or in the accom-
panying information, at the end of the product's useful
life it must not be disposed of with other domestic waste.
