Product Safety Information

Intended Use:
These Air Impact Wrenches are designed to remove and install threaded fasteners.
For additional information refer to Product Safety Information Manual Form 04580916.
Manuals can be downloaded from ingersollrandproducts.com.

Product Specifications

Models Style
Outside
3955A2Ti
Trigger
Inside
3955B1Ti
Trigger
Inside
3955B2Ti
Trigger
Inside
3955B2TiEX
Trigger
Models
† Pressure (L
3955A2Ti
3955B1Ti
3955B2Ti
3955B2TiEX
† K = 3dB measurement uncertainty
pA
‡ K = 3dB measurement uncertainty
wA
Sound and vibration values were measured in compliance with internationally recognized
test standards. The exposure to the user in a specific tool application may vary from these
results. Therefore, on site measurements should be used to determine the hazard level in
that specific application.
Installation and Lubrication
Size air supply line to ensure tool's maximum operating pressure (PMAX) at tool inlet. Drain
condensate from valve(s) at low point(s) of piping, air filter and compressor tank daily. Install a
properly sized Safety Air Fuse upstream of hose and use an anti-whip device across any hose
coupling without internal shut-off, to prevent hose whipping if a hose fails or coupling
disconnects. See drawing 47132782 and table on page 2. Maintenance frequency is shown in a
circular arrow and defined as h=hours, d=days, and m=months of actual use. Items identified as:
1. Air filter
2. Regulator
3. Lubricator
4. Emergency shut-off valve
80160716_ed8
Drive Impacts
per
Type Size
min.
Square 1.5" 700
Spline No. 5 700
Square 1.5" 700
Square 1.5" 700
Sound Level dB(A)
(ISO15744)
)
p
101.5
101.5
101.5
101.5
WARNING
5. Hose diameter
6. Thread size
7. Coupling
8. Safety Air Fuse
Recommended Torque Range
Forward
ft-lbs (Nm)
1600-3900 [4700 Max.]
(2170-5290 [6370 Max.])
1600-3900 [4700 Max.]
(2170-5290 [6370 Max.])
1600-3900 [4700 Max.]
(2170-5290 [6370 Max.])
1600-3900 [4700 Max.]
(2170-5290 [6370 Max.])
‡ Power (L )
w
112.5
112.5
112.5
112.5
*K= Vibration measurement uncertainty
9. Oil
10. Grease - during assembly
11. Grease - through fitting
Reverse
ft-lb (Nm)
1600-4150 [5000 Max.]
(2170-5630 [6780 Max.])
1600-4150 [5000 Max.]
(2170-5630 [6780 Max.])
1600-4150 [5000 Max.]
(2170-5630 [6780 Max.])
1600-4150 [5000 Max.]
(2170-5630 [6780 Max.])
Vibration (m/s²)
(ISO28927)
Level *K
20.8 8.5
20.8 8.5
20.8 8.5
20.8 8.5
