Checking Accessories/Part Names and Functions

Accessories

This product contains the following
parts.
•
Main unit
•
Bracket
•
USB cable
•
Strap
•
Quick Start Guide (this manual)
•
Important Information for the User
•
Warranty Card

Part Names and Functions

Front View

Display (touch panel)
Touch the screen to select an item or
switch screens.
[LAP] button
Press the [LAP] button during logging to
record a lap.
Press the [LAP] button for more than 2
seconds to reset the timer and record the
log.
For details, refer to page 19.
[START/STOP] button
Press the [START/STOP] button to start
or stop logging. Press the [START/STOP]
button for more than two seconds to turn
the power on or off.
EN
5
