DJI P4 MULTISPECTRAL Kurzanleitung Seite 8

Multi-Frequency Multi-System High-
Precision RTK GNSS
● Mapping Functions
Ground Sample Distance (GSD)
Rate of Data Collection
●
Gimbal
Controllable Range
● Vision System
Velocity Range
Altitude Range
Operating Range
Obstacle Sensory Range
Operating Environment
● Camera
Sensors
Filters
Lenses
RGB Sensor ISO Range
Monochrome Sensor Gain
Electronic Global Shutter
Max Image Size
Photo Format
Supported File Systems
Supported SD Cards
Operating Temperature
●
Remote Controller
Operating Frequency
Transmission Power (EIRP)
Max Transmission Distance
Built-in Battery
Operating Current / Voltage
Mobile Device Holder
Operating Temperature
● Intelligent Flight Battery (PH4-5870mAh-15.2V)
Capacity
Voltage
Battery Type
Energy
Net Weight
Operating Temperature
Charging Temperature
Max Charging Power
●
Intelligent Flight Battery Charging Hub (P4CH)
Voltage
Operating Temperature
●
AC Power Adapter (PH4C160)
Voltage
Rated Power
[1] To comply with local laws and regulations, this frequency is not available in some countries or regions.
[2] Support for Galileo is coming soon.
Frequency Used
GPS: L1/L2; GLONASS: L1/L2; BeiDou: B1/B2; Galileo
First-Fixed Time: < 50 s
Positioning Accuracy: Vertical 1.5 cm + 1 ppm (RMS); Horizontal 1 cm + 1 ppm (RMS).
1 ppm indicates error with a 1 mm increase over 1 km of movement.
Velocity Accuracy: 0.03 m/s
(H/18.9) cm/pixel, H indicates the aircraft altitude relative to the area mapped (unit: m)
Max operating area of approx. 0.47 km
approx. 9.52 cm/pixel
Pitch: -90° to +30°
≤ 31 mph (50 kph) at 6.6 ft (2 m) above ground with adequate lighting
0 - 33 ft (0 - 10 m)
0 - 33 ft (0 - 10 m)
2 - 98 ft (0.7 - 30 m)
Surfaces with clear patterns and adequate lighting (> 15 lux)
Six 1/2.9" CMOS, including one RGB sensor for visible light imaging and five monochrome sensors for
multispectral imaging.
Each Sensor: Effective pixels 2.08 MP (2.12 MP in total)
Blue (B): 450 nm ± 16 nm; Green (G): 560 nm ± 16 nm; Red (R): 650 nm ± 16 nm;
Red edge (RE): 730 nm ± 16 nm; Near-infrared (NIR): 840 nm ± 26 nm
FOV (Field of View): 62.7°
Focal Length: 5.74 mm (35 mm format equivalent: 40 mm), autofocus set at ∞
Aperture: f/2.2
200 - 800
1 - 8x
1/100 - 1/20000 s (visible light imaging); 1/100 - 1/10000 s (multispectral imaging)
1600×1300 (4:3.25)
JPEG (visible light imaging) + TIFF (multispectral imaging)
FAT32 (≤ 32 GB); exFAT (> 32 GB)
microSD with a minimum write speed of 15 MB/s. Max Capacity: 128 GB. Class 10 or UHS-I rating
required
0° to 40° C (32° to 104° F)
2.4000 GHz to 2.4835 GHz (Europe, Japan, Korea)
5.725 GHz to 5.850 GHz (Other countries/regions)
2.4 GHz: < 20 dBm (CE / MIC / KCC)
5.8 GHz: < 26 dBm (FCC / SRRC / NCC)
FCC / NCC: 4.3 mi (7 km); CE / MIC / KCC / SRRC: 3.1 mi (5 km)
(Unobstructed, free of interference)
6000 mAh LiPo 2S
1.2 A @ 7.4 V
Tablets and smartphones
0° to 40° C (32° to 104° F)
5870 mAh
15.2 V
LiPo 4S
89.2 Wh
468 g
-10° to 40° C (14° to 104° F)
5° to 40° C (41° to 104° F)
160 W
17.5 V
5° to 40° C (41° to 104° F)
17.4 V
160 W
[2]
: E1/E5
2
for a single flight at an altitude of 180 m, i.e., GSD is
[1]
136 mm
71 mm
7
