COMFORTPOOL CP-80023 Installation / Benutzerhandbuch Seite 19

Remarks: The port of the four-way valve has both internal and external threads, choose the connection method
according to the actual situation. If yours is INTEX hose, you can use external thread connection. If it is a
commonly used 1-1/4 inch or 1-1/2 inch hose, use the internal thread.
Union with threads on both ends
Build-in plug of port C, port D is in its opposite position
7. Insert the outlet pipe, screw to build-in plug of Port C, measure the actual size of the backflow, 5CM is
suggested.
8. Cut the outlet pipe to a proper length, use PVC glue to connect to matching elbow.
Port D
For 1-1/2" hose
For 1-1/4" hose
Cut to proper length
Apply PVC glue here
Threads for Intex hose
Suggested distance 5 cm
19
