Audio inputs

1. AUX/Line In mode

• Press the " " button on the active speaker, or press the "
or Line In mode (the green indicator will flash and then will be steady lit);
• Connect audio source (mobile phone, tablet, etc.) to the "AUX" or "Line In" input port (note color matching) on the rear panel
of the active speaker using audio cable;
• Play music on the connected device and adjust the settings to a desired level.

2. Optical mode

• Press the " " button on the active speaker, or press the "
red indicator will flash once and then will be steady lit);
• Connect audio source (DVD, Set Top Box, etc.) to the "OPT" input port on the rear panel of the active speaker using fiber optic
audio cable;
• Play music on the connected device and adjust the settings to a desired level.
3. Coaxial mode
• Press the " " button on the active speaker, or press the "
(the red indicator will flash twice and then will be steady lit);
• Connect audio source to the "COAX" input port on the rear panel of the active speaker using coaxial cable (coaxial cable not
included);
• Play music on the connected device and adjust the settings to a desired level.
8
English
or
" or " " button on the remote control to switch to AUX
" button on the remote control to switch to optical mode (the
" button on the remote control to switch to coaxial mode
