TECHNICAL CHARACTERISTICS

• Standards:
IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, IEEE 802.3z
1000BASE-X Gbit/s Ethernet over Fiber-Optic, IEEE 802.3x Full Duplex and fl ow control,
IEEE 802.3af Power over Ethernet, IEEE 802.3at Power over Ethernet Plus, IEEE 802.3bt
4PPoE
• Ports: 16x 10/100/1000Base-T RJ45, Auto-MDI/MDI-X, 2x 1000Mbps SFP
• PoE ports: 1-16
• PoE budget: 300W
• Total output: 330W
• LCD display: Real-time display of PoE operating status
• PoE output power: Port 1-4 max. 60W, port 5-16 max. 32W
• LED indicators: PWR, LNK/ACT, PoE
• Network cable: Cat. 5e/6/6A/8.1 cable (≤ 100m)
• 1000BASE-SX: MMF, SMF
• MAC address table: 8K, automatic learning, automatic updates
• Jumbo Frame: 9216 Bytes
• Packet buffer: 4.1Mbit
• Transmission method: Store-and-forward
• Packet forwarding rate: 26.78 million packets per second
• Bandwidth: 36Gbit
• Number of fans: 3
• Dimensions (W x D x H): 440x232x45mm
• Weight: approx. 3.2kg
• Mains input: 100~240V AC, 50/60Hz
•

Environmental conditions:

Operating temperature -10-60°C, storage temperature -40-70°C, humidity in operation
10-90% non condensing, humidity during storage 5-90% non condensing
• Surge protection: ± 6KV
