Cleaning Module-II
Tubing
Operation with If only one cleaning solution is used, channel 11 (canister and sole-
noid valve on the right side) is pumped.
one cleaning
solution Make the following modifications to the tube connections:
1 Remove all tubes (pump tube, reagent tubes) belonging to
2 Disconnect the tube leading to the monitor from the distribution
16
channel 12.
block outlet [C] and connect it directly to the remaining pump
tube [B].
A
B
C
12 11
D
A Peristaltic pump
B
Pump tube
C
Distribution block
D Solenoid valve 11
(active channel)
E Tube 14 or 15 leading
to the instrument
F
Pump tube of channel
12
F
E
