Description
Fig. 1-1 View of the EB1 optional board
1-2
All manuals and user guides at all-guides.com
Fixing
screw
64-pole system
connector
Jumper X486,
X487, X488
Fixing
screw
EB1 - Expansion Board 1
X480
X481
477 791 4070 76 J AA-74
Operating Instructions
SIMOVERT MASTERDRIVES
