Router mode

In router mode, the product provides a WLAN network and Internet access.
Bandwidth is limited to 100 Mbps.
Configuring the product
Configuration can take place away from the operating location.
Requirements:
• The product is switched on.
1. Slide the mode selector switch to Router.
2. Log into the web interface.
3. Go to . The settings window opens.
Wizard
4. Configure the Internet connection:
- Decide if your connection uses DSL (select PPoE), a static IP (select
namic IP (select Dynamic IP) connection. Check with your Internet service provider if
needed.
- Enter the required details for the selected connection type.
5. Configure the wireless network:
- Enter a network SSID (network name) into the
- Select network authentication:
Weakest: OPEN (no security,
Strongest: WPA2-PSK (recommended)
Device compatibility: Ensure your devices support the selected option.
- Enter a network password into the
6. Click on to save the changes.
Apply
» The product is ready to be connected to the Internet.
Connecting the product to the Internet
1. Plug the modem cable into the WAN/LAN port on the product.
» On successful signal detection, the WAN/LAN indicator is lit.
» The product is now ready to accept network hosts (e.g. computer, smartphone).
Connecting devices
Connect network hosts (e.g. computer or smartphone) to the product for network access.
You can connect hosts wirelessly or using a network cable.
Requirements:
• The product is switched on and configured in router mode.
• The product is connected to the Internet.
a) Wireless connection
1. Connect to the product WLAN network. Use the configured SSID (network name) and pass-
word.
b) Network cable
1. Connect your device to the LAN port (max. 100 Mbps) on the product using a network
cable.
Viewing network status
You can view network metrics on the status dashboard.
1. Log into the web interface.
2. Go to . The status dashboard opens.
Status
• Click on to view the detailed client list.
Clients
Further configuration
Further configuration options are available through the web interface.
Explore the and
Setup Wi-Fi
Make sure you understand what the settings do before you change them. Some are meant for
advanced users with specialist knowledge.
Backing up and restoring configurations
Save a backup file of the current configurations.
Restore settings from a backup file.
1. (If switched off) switch the product on.
2. Log into the web interface.
3. Go to
Setup > Backup/Restore
4. Depending on your needs, follow the backup or restore instructions.
field.
Wi-Fi SSID
not recommended!)
field. Use a strong password.
Wi-Fi Password
pages.
Settings. The settings window opens.
Resetting
Resetting the product restores the default settings (including passwords).
1. (If the product operates in router mode) disconnect it from the Internet.
2. (If switched off) switch the product on.
3. Use a paper clip and hold down the Reset button for 3 seconds.
4. Wait for the indicator lights to light up again.
» The product is reset.
Care and cleaning
• Disconnect the product from the mains before each cleaning.
• Do not use any aggressive cleaning agents, rubbing alcohol or other chemical solutions as
they can cause damage to the housing and malfunctioning.
• Clean the product with a dry, fibre-free cloth.
Declaration of Conformity (DOC)
Static IP) or dy-
Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau hereby declares that this
product conforms to the 2014/53/EU directive.
Click on the following link to read the full text of the EU declaration of conformity:
www.conrad.com/downloads
Enter the product item number in the search box. You can then download the EU
declaration of conformity in the available languages.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the house-
hold waste. At the end of its service life, dispose of the product in accordance with
applicable regulatory guidelines.
You thus fulfill your statutory obligations and contribute to the protection of the envi-
ronment.
Technical data
Operating voltage ......................... 100 – 240 V/AC, 50/60 Hz, max. 0.3 A
LAN ............................................... 1x RJ45 LAN 10/100 Mbps
WLAN ........................................... IEEE 802.11b/g/n, 2.4 GHz, max. 300 Mbps;
Frequency range .......................... 2.412 – 2.472 GHz (802.11b/g/n)
Range ........................................... Indoors: max. 100 m / Outdoors: max. 300 m
Transmission power...................... max. 20 dB
Network security ........................... WPA-PSK/WPA2-PSK
Operating modes .......................... Repeater / Access point / Router
Operating conditions ..................... 0 to +40 °C, 10 – 90 % RH (non-condensing)
Storage conditions ........................ -10 to +70 °C, 10 – 90 % RH (non-condensing)
Dimensions (W x H x D) ............... approx. 81 x 94 x 81 mm
Weight .......................................... approx. 97 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights in-
cluding translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represent the technical status at the time of printing.
Copyright 2020 by Conrad Electronic SE.
1x RJ45 WAN/LAN 10/100 Mbps
