Description; Design; Function - Signode Josef Kihlberg 561-15PN Betriebsanleitung

4
1
Fig. 1
04.20

DESCRIPTION

4
3
2

4.1 DESIGN

1 Adjustment penetration depth
2 Pusher
3 Trigger
4 Compressed air connection

4.2 FUNCTION

The top stapler 561-15PN has only single shot firing
without safety yoke.
1. Press the top stapler against the carton and pull
the trigger (Fig.1/4).
2. Move the stapler and repeat.
Never fire it without any work piece.
Warning: before stapling ensure that
your hand or any other part of your
body is not underneath the nozzle.
Josef Kihlberg 561-15PN
