ASSEMBLY
1
Hardware Qty
A Bolt 4
B Flat Washer 4
2
Hardware Qty
E Flat Washer (25mm) 2
F Flat Washer (19mm) 2
G Spring Washer 2
H Bolt (20mm) 2
ENGLISH
3
Hardware
I Bolt (35-20mm)
A
J Nut
B
Pre-installed
4
Hardware
K Screw
Torque Value
L Bolt
40 Nm / 29 ft-lb
M Screw
1 LCB Communication
2 Extension Power Wire
3 Heart Rate Wire
E F H 4 Quick Key Wire
5 Ethernet
6 Coax
7 Ground Wire
1
G
ASSEMBLY COMPLETE
6
Qty
2
2
Qty
8
4
2
2 3 4 5 6 7
K
J
I
L
M
