MINI PAK'R
®
Parts
Table of Table of
Contents Contents

External Parts

Power Cord, Power Switch,
1
Fuse
Air Filling Tube
2
3 Control Panel
Upper Belt Cover
4
Lower Belt Cover
5
Quick Reference Guide
6
7 Film Roll Holder
MINI PAK'R 제조기 사용자 설명서 -6- 페이지
MINI PAK'R Machine User Manual Page -6-
How the MINI PAK'R Machine Works
• Load any approved MINI PAK'R Film Roll onto Film Roll Holder (7).
• The right side of the Film is guided onto the Air Fill Nozzle (8) and pulled through the machine.
• The Seal Belts (10 and 13) and Driver Rollers (12) advance the film.
• Air is injected by the Air Pump (14) through the Air Fill Nozzle (8), creating Air Cushions.
• The inflated Air Cushions are sealed by the Hot Sealing Bar (11).
• The right edge of the film is then cut from the Air Fill
Nozzle (8) by the Slitting Blade.
MINI PAK'R Machine User Manual Page -7-
Internal Parts
Film Roll Holder
7
8 Air Fill Nozzle
9 Belt Release Lever
10 Upper Teflon Seal Belt
11 Hot Sealing Bar
12 Drive Rollers
13
Lower Teflon Seal Belt
14 Air Pump
