Technical Data; Safety - Pregis AirSpeed MINI PAK'R Bedienungsanleitung

Technical MINI PAK'R Machine
The
protective wrap, and general transport packaging. Strict compliance with the safety
Data
instructions are required to ensure personal safety (See Safety Instructions in this manual).
Specification
Film Roll Product Preconfigured film for MINI PAK'R Machine
Production Rate 7.5 meters per minute (25 ft./minute)
Power Rating Model # MMP01MNPKR ( Item # 4075536 ) - 120V 3.15A
Model # MMP02MNPKR ( Item # 4075540 ) – 230V 1.6A
Machine Dimensions 33cm (13") wide X 36cm (14") long X 28cm (11") tall
Recommended Power Fuse 5mm X 20mm, Slow-Blow: 110V 3.15A, 230V 1.6A
Maximum Roll Diameter Up to 175mm (6.9")
Width of Roll Up to 400mm
Machine Weight 6 kg (13.5 lbs.)
creates air cushions on-demand for use as cushioning,
MINI PAK'R 제조기 사용자 설명서 -4- 페이지
MINI PAK'R Machine User Manual Page -4-
To ensure the personal safety of operating personnel and/or users of this machine, the
instructions below must be followed at all times.

Safety

Table of
1. Avoid all contact with internal electrical components.
Instructions Contents
2. In case of emergency, press the red STOP button. The machine will stop. Once a fault
has been corrected, the machine can be restarted following the directions below.
3. If the machine is not used for any length of time, the Power Switch must be turned OFF
at the rear of the machine.
4. During Installation and Maintenance, the Power Switch must be in the OFF position,
!
with the Power Cord disconnected.
5. All safety and protection measures must be fitted and adequately maintained in
accordance with Iocal regulations.
6. Only trained and qualified service personnel may maintain any electrical and or
mechanical part of the machine.
7. Machines are supplied preset and fully tested. Any loss arising from production
downtime and failure of the machine caused by incorrect operation, poor or faulty
maintenance, or the use of materials other than those provided by
Pregis shall void the terms of the warranty.
8. During machine operation, NEVER touch the film at its point of entry into the
machine. Do not attempt to guide the film into the machine. Injury may result.
9. Under no circumstances may any installed safety feature be overridden.
10. After loading the Film Roll, the machine will automatically adjust to the right seal
temperature for the film. Any contact with the heating element must be avoided
(or any part in direct contact with the heating element) since it may remain hot
for several minutes after the machine has been switched OFF.
MINI PAK'R Machine User Manual Page -5-
-5- 페이지
