Housing and operating elements

1
2
3
4
5
6
7
8
9
10
1 Hanging loop
2 Sealing screws (fixing of terminal cover)
3 Test-LED
4 LC-display
5 Nameplate
6 Terminal cover
7 Terminal block
8 Sealing screws (fixing of terminal cover)
9 Fastening holes
10 Ground for cable glands
11 Cable glands
Front view
11
22
Side view from left
10
