TAV.
RIF.TO
CODICE
TABLE
REF.
PART No.
9
1
3007476
9
2
3007837
9
3
3007838
9
4
4300036
9
5
3007375
9
6
4300447
9
7
4300476
9
8
2107841
9
9
4200755
9
10
4200754
9
11
2107843
9
12
3007844
9
13
4300040
9
14
4300053
9
15
3008424
9
16
3007471
9
17
4200880
9
18
4200876
9
19
4200879
9
20
4300039
9
21
4300244
9
22
3005048
9
23
4200402
9
24
4200883
9
25
4200787
9
26
4200788
9
27
4300048
9
28
4300047
9
29
4300293
9
30
4200491
9
31
4200790
9
32
3003922
9
33
4300029
9
34
4300051
9
35
4200783
9
36
4300045
9
37
4200784
9
38
4200786
9
39
3002555
9
40
4300224
9
41
3007060
9
42
3001656
9
43
3002265
9
44
4300327
9
45
3008793
9
46
4200691
9
47
4300079
9
48
3009079
9
49
4300222
9
50
3008565
9
51
4300044
9
52
4300185
9
53
4200782
9
54
4201830
9
55
4201094
9
56
4200789
9
57
4200886
9
58
3008052
9
59
4300148
9
60
3008114
9
61
3008396
9
62
3008395
9
63
3007836
DESCRIZIONE
PERNO SUPPORTO RUOTA ANTERIORE
MASSA FRENO 180X40 DX CON LEVA
MASSA FRENO 180X40 SX CON LEVA
ROSETTA D.8,4X17 UNI 6592 ZINC.
RONDELLA
GHIERA M25X1,5
VITE TSPEI M14X40 UNI 5933 ZINC.
LEVA FRENO DX
FORCELLA LUNGA M6
CLIP LUNGA M6
LEVA FRENO SX
CAVETTO PER MASSA FRENO
VITE TE M8X40 UNI 5739 ZINC.
DADO M8 AUTOFRENANTE UNI 7473 ZINC.
MOLLA TRAZIONE TR46
MOZZO FOLLE RUOTA ANTERIORE
PARAOLIO 30.47.7
CUSCINETTO CONICO 30204
CUSCINETTO CONICO 32005
RONDELLA D. 17X 30 UNI 6592 ZINC.
DADO AUTOBLOCC. M16X1,5 UNI 10331
RUOTA PNEUMATICA 6.00.9 - 12 TELE
COLONNETTA SERRAGGIO RUOTE M16 X 1,5
CALOTTINA COPRIMOZZO D.47
PEDALE FRENO
POMPA FRENO
RONDELLA D.6,4 X 12 UNI 6592 ZINC.
VITE TE M6 X 16 UNI 5739 ZINC.
VITE TE M8 X 25 UNI 5739 ZINC.
RONDELLA BONDED SEAL 1/4"
RACCORDO AD OCCHIO M10X1,25
RACCORDO FORATO M12X1,5
DADO M8 UNI 5588 ZINC.
DADO M6 AUTOFRENANTE UNI 7473 ZINC.
STAFFA PER SERBATOIO
RONDELLA D.5,5 X 15 UNI 6593 ZINC.
SERBATOIO OLIO FRENO
LEVA FRENO A TIRO ORIZZONTALE
CAVETTO FRENO A MANO
RONDELLA D.6,4 X 18 UNI 6593 ZINC.
CARRUCOLA FERRO
FORCELLA SUPPORTO CARRUCOLA
PERNO PER FORCELLA CARRUCOLA
SEEGER PER ALBERO D.8 UNI 7435
FUNE FRENO A MANO
FASCETTA STRINGITUBO 10-16
DADO MEDIO M6 UNI 5588 ZINC.
TUBO OLIO IN GOMMA L.1350
VITE TBEI M8 X 20 UNI 7380 ZINC.
TUBO IN RAME L.1250
VITE TE M5X15
VITE TE M6X30
TUBO RAME 3X5 L.850
ROND. BONDED SEAL 1/4" AUTOCENTRANTE
RONDELLA RAME 1/8"
RACCORDO A 3 VIE M10X1,25
PRESSOSTATO PER STOP
FERMO PER TUBO FRENO
VITE TBEI M6 X 10 ISO 7380 ZINC.
FLANGIA SPESSORAMENTO RUOTA ANTERIORE
COPPIA GANASCIE FRENO CON LEVA
REGISTRO MASSA FRENO CON LEVA
CILINDRETTO SPECIALE D.15,87
PB 200 - 65
PB 17 0 - -
DESCRIPTION
Front wheel shaft
Right brake plate
Left brake plate
Flat whasher D 8,4X17 ISO 7089 Galvanized
Washer
Selr locking ring M25x1,5
Screw M14x40 ISO 10642/Galvanized
Right brake lever
Fork M6
Fork locking M6
Left brake lever
Brake cable
Hexagon screw M8x40 ISO 4017/Galvanized
Hexagon self- locking nut M8 ISO 7040
Sping TR46
Front wheel hub
Rotary shaft seal 30.47.7 ISO 6194
Tapered roller bearing 30204
Tapered roller bearing 32005
Flat whasher D.17x30 ISO 7089 Galvanized
Selr locking nut M16x1,5
Wheel
Fixing screw M16x1,5
Cover hub bowl D.47
Brake pedal
Brake pump
Flat whasher D 6,4x12 ISO 7089 Galvanized
Hexagon screw M6x16 ISO 4017/Galvanized
Hexagon screw M8x25 ISO 4017/Galvanized
Bonded seal washer 1/4 "
Eye shaped union M10x1,25
Union 12x1,5
Hexagon nut M8 ISO 4032/Galvanized
Hexagon self- locking nut M6 ISO 7040
Bracket for tank
Washer D.5,5x15 ISO 7093 Galvanized
Tank for oil brake
Brake lever
Handbrake cable
Washer D.6,4 x 18 ISO 7093 Galvanized
Pulley
Fork pulley support
Pulley fork pin
Seeger ring D.8 DIN 6799
Hand brake cable
Hose clamp 10-16
Hexagon nut M6 ISO 4032/Galvanized
Rubber hose
Screw TBEI M8 X 20 ISO 7380/Galvanized
Copper pipe 3x5
Screw M5X15
Screw M6X30
Copper pipe 3x5
Bonded seal washer 1/4 " self centering
Copper washer 1/8"
3 way connector M10X1,25
Stop pressure switch
Stop for copper pipe
Screw TBEI M6 X 10 ISO 7380/Galvanized
Wheel spacer
Pair brake shoes with lever
Adjustment brake lever
Brake cylinder D.15,87
