INSTALLATION

Fig.1 - DIMENSIONS (mm):
85
IMPORTANT:
> The installation of this device must be carried out by specialist technicians.
> Caution, do not connect the battery charger
- when a generator set with non stabilised output voltage is employed
- with power mains voltage exceeding the rated value (230V
> Do not carry out any maintenance when the battery charger is connected to the
230V
> In case of battery charger misuse, the guarantee becomes invalid and the manufacturer
declines all responsibility for damages to people and property.
> This appliance can be used by children aged 8 years
physical, sensory or mental capabilities or lack of experience
provided they are being supervised or they have been i
the appliance in a safe way and
not play with the appliance.
BATTERY CHARGER
- Install the battery charger in an appropriate housing,
dry and ventilated; maximum efficiency can be
obtained w hen the battery charger is installed in a
vertical position (see figure 2), keeping the front at a
minimum istance of 300 mm and the bottom and top d
at a minimum distance of 100 mm from the housing
sides.
- Do not cover air intakes.
- T o guarantee proper air exchange, installation of
two air intakes (one placed on the top and one on
the ottom, see figure 2) ensure a working b
temperature inside the housing not exceeding
50°C.
- M ake sure that the 230V
easily reached.
- T he connection to power supply mains shall be
made in accordance with national installation rules.
- B efore disconnecting the battery charger from
230V power supply, turn the safety switch off.
- I nstallation requires the fixing of 4 pins that can be
easily placed on the 4 sides.
- T he battery charger can be installed together with
CBE 12V and 230V distribution panels, using the
10 appropriate modular joints.
157
110
140
power supply net.
that they
safety switch can be
Fig.2 - VERTICAL INSTALLATION
:
or more
nstruct
understand the hazards involved. Children shall
CABLES
- M ains connection: use a 3x1.5mm² cable, type
H05 RN-F or equivalent.
- B attery connection: use N07 V-K cables having
adequate cross section (minimum
4mm²).
- F ix the cables with the relevant
devices supplied.
- Protect cables from any possible damage.
BATTERY
- Lead-acid batteries shall be positioned in a well
ventilated place.
- U se only 12V (6 cells)
(capacity >40Ah).
WARNING:
> Do not use with "not rechargeable" batteries.
> Exhausted batteries shall be disposed in
accordance with existing environmental
protection regulations.
±10%)
and people with reduced
or knowledge , only
ed concerning the use of
cross section
cable fastenings
rechargeable lead batteries
