IMI HEIMEIER / Floor Heating Control / Mulibox 4
Accessories
Compression fitting
for copper or precision steel pipe.
Brass nickel-plated.
With a pipe wall thickness of 0.8-1 mm
insert supporting sleeves. Heed pipe
manufacturer's technical advice.
Support sleeve
for copper or precision steel pipe with a
1 mm wall thickness.
Brass.
Compression fitting
for copper or precision steel pipe.
Brass nickel-plated.
Soft sealed.
Compression fitting
for plastic pipe.
Brass nickel-plated.
Compression fitting
for multi-layer pipes.
Nickel-plated brass.
Spindle extension for K thermostatic
head with Multibox 4 K-RTL
when maximum installation depth
exceeded.
Spindle extension for RTL
thermostatic head with Multibox 4 RTL
when maximum installation depth
exceeded.
Brass nickel-plated.
Ø Pipe EAN
12 4024052214211
15 4024052214617
16 4024052214914
18 4024052215218
Ø Pipe L EAN
12 25,0 4024052127016
15 26,0 4024052127917
16 26,3 4024052128419
18 26,8 4024052128815
Ø Pipe EAN
15 4024052515851
18 4024052516056
Ø Pipe EAN
14x2 4024052134618
16x2 4024052134816
17x2 4024052134915
18x2 4024052135110
20x2 4024052135318
Ø Pipe EAN
16x2 4024052137312
L EAN
Brass nickel-plated
20 4024052528813
30 4024052528912
Plastic, black
15 4024052553310
30 4024052165018
L EAN
20 4024052500215
Article No
3831-12.351
3831-15.351
3831-16.351
3831-18.351
Article No
1300-12.170
1300-15.170
1300-16.170
1300-18.170
Article No
1313-15.351
1313-18.351
Article No
1311-14.351
1311-16.351
1311-17.351
1311-18.351
1311-20.351
Article No
1331-16.351
Article No
2201-20.700
2201-30.700
2001-15.700
2002-30.700
Article No
9153-20.700
