TYPENSCHILD | TYPE LABEL
Tischtyp
Desk type
type: GB-xx-xx
Monteur
assembler: 4444 week/year: xx/2019
Assembler
ackn.no.: AB 291123/4
gas springs [N]: 150N
input: 230V AC / 50Hz / 2,5A
duty cycle: 30sec/270sec
Elektrische Angaben
Electrical details
Einschaltdauer
Gasfederbestückung
Beispiel: eine 30-sekündige Aktivität (motorische Auf-/
Gas spring assembly
Ab-Bewegung der Tischplatte) erfordert anschließend eine
Auftragsbestätigung
270-sekündige Pause.
Order confirmation
Duty cycle
Example: a 30 second long activity (motorized up/down
movement of the desk top) requires a break of 270
seconds afterwards
Das Typenschild befindet sich auf der Unterseite der Quertraverse.
The type plate can be found on the underside of the cross rail.
Herstelldatum
Date of manufacture
Adresse des Herstellers
Address of the manufacturer
Hauptstraße 2-4
96484 Wiesenfeld
Tel. 09566/88-0
info@leuwico.com
www.leuwico.com
max. 75 kg
Maximalbelastung Tischplatte
Maximum load on desk top
