ON / OFF Switch
Slide the switch
UP for ON and
DOWN for OFF
Dual Function
Adjust the servo angle by turning the switch up or down.
Turn the swich in upper position for larger servo angle.
Turn the swich in lower position for smaller servo angle.
Servo Reversing Switches
If the direction of travel on the
rudder is backwards, slide the
steering reverse switch to the
other position.
It is same principle for the throttle
reverse switch.
www
4
Switch Up for
Larger Servo Angle
Battery LED Monitor
Solid Red:
Battery is in good
condition (Above
4.3V)
Flashing Red:
Battery is at low
voltage
Replace batteries
(below 4.3V)
Switch Down for Smaller
Servo Angle
Throttle Reverse Switcher
Steering Reverse
Switcher
Brushed Transmitter
