Bosch Rexroth PSI 6 224 Serie Typspezifische Anleitung Seite 48

48/59 Bosch Rexroth AG
Input/Output array
Tab. 18: Serial output field
Bits Outputs (word 2):
Bit_032 Prop valve selection Bit 00
Bit_033 Prop valve selection Bit 01
Bit_034 Prop valve selection Bit 02
Bit_035 Prop valve selection Bit 03
Bit_036 Prop valve selection Bit 04
Bit_037 Prop valve selection Bit 05
Bit_038 Prop valve selection Bit 06
Bit_039 Prop valve selection Bit 07
Bit_040 Prop valve selection Bit 08
Bit_041 Prop valve selection Bit 09
Bit_042 Prop valve selection Bit 10
Bit_043 Prop valve selection Bit 11
Bit_044 Prop valve selection Bit 12
Bit_045 Prop valve selection Bit 13
Bit_046 Prop valve selection Bit 14
Bit_047 Prop valve selection Bit 15
Tab. 19: Serial output field
Bits Outputs (word 3):
Bit_048 PSQ evaluation completed
Bit_049 PSQ evaluation ok
Bit_050 Not used
Bit_051 Not used
Bit_052 Not used
Bit_053 Not used
Bit_054 Not used
Bit_055 Not used
Bit_056 Reference weld active (since firmware version -108)
Bit_057 Monitoring weld active (since firmware version -108)
Bit_058 Tipp dressing defective (since firmware version -108)
Bit_059 Not used
Bit_060 Acknowledge end of component (since firmware version -110)
Bit_061 Q-Stopp (since firmwareversion -110)
Bit_062 Not used
Bit_063 Not used
1070087028 | PSI 6xxx.224
