34/59 Bosch Rexroth AG
To this Documentation
Meaning of the Symbols
Tab. 2:
Symbol Meaning
If this information is disregarded, the product cannot be
used and or operated to the optimum extent.
Single, independent step

1. Numbered step:
2. The numbers specify that the Steps are completed one
after the other.
3.
1.3.3

Designations

This documentation uses the following designations :
Designation
Tab. 3:
Designation Meaning
BOS 6000 Bedienoberfläche Schweißen (Welding Software)
PSG xxxx
Medium-Frequency Welding Transformer 1000Hz
1.3.4

Abbrevations

The in this documentation used abbrevations please look in Tab. 1: Required and
supplementary documentation Rexroth PSI6xxx Medium-Frequency Inverter
Instruction Manual.
1070087028 | PSI 6xxx.224
