DESCRIPTION

1
8
2
4

4.1 DESIGN

1 Tensioning lever
2 Rocker lever
3 Tension wheel and toothed plate
4 Strap guides (4 pcs)
5 Upper and lower punch
6 Lock screw (cutting depth)
7 Adjusting screw (cutting depth)
8 Sealing lever

4.2 FUNCTION

– Strap clamped by pressure on toothed plate
( Fig. 2/2).
– Tensioning by feed wheel principle (2/1).
– Sealing by punching strap (2/3).
– Strap cut with knife (2/4).
Josef Kihlberg JK1219HT
