8.4 Activation handle

The activation handle is equipped with a blank cartridge. By
attaching the handle to the coupler at the shoulder strap of the
backpack and then pulling the activation handle, the blank
cartridge will ignite. The explosion pressure travels through the
tube to the puncture unit. There a cartridge containing nitrogen
will be pierced with the pin and the nitrogen is forced through the
pressure tubes to the two airbags where in combination with the
suction and release valve the airbags get inflated. Inflation time is
approx. 2 – 3 seconds!

8.5 Cartridge

The cartridges contain only harmless gas, the same as in our air.
The inside pressure is 300 bar (Carbon cartridge 340 bar). The
piercing of the cartridge should only occur within the puncture
32
unit of the ABS-system. Any manipulation at the closure or at the
cartridge can trigger an explosion which may result in a high risk
of injury and or death, including bystanders.
Each cartridge is designed for temperatures from -40ºC to +50ºC
(-40F to +122 F). Empty cartridges can only be filled by ABS.
The exchange can only be done at an ABS retail shop. Avoid
impacts such as dropping the cartridge.
Depending on the model, the cartridges comply with the
following guidelines:
– Steel cartridge Europe: EG guidelines
– Steel cartridge North America: DOC and TC certified
– Carbon cartridge: EG guidelines

8.6 Carrying system

The authorized carrying systems are identified by the ABS logo.
The various straps and belts comply with the TÜV requirements
for extreme operational demands. The tensile strength for all
weight bearing straps equals 3000N (674lbs). In order to ensure
that the ABS Avalanche Airbag System stays on the person's
body during an avalanche, it is imperative that the waist belt,
chest strap and leg straps are properly fastened. The greatest
chance that the ABS Avalanche Airbag to remain on your body
during an Avalanche is if waist belt, chest strap and leg straps
are properly fastened.

9. Storage and cleaning

Make sure before each use that the full cartridge is screwed in
tightly and check the weight as described in steps 1 and 2 of the
Initial Operation. Otherwise you can leave the cartridge attached.
Always make sure that the protective cap is on the cartridge
when the cartridge is not attached to the airbag. It is recommen-
ded to remove the handle after each use. The ABS Avalanche
Airbag should be stored in a dry, rodent free area and away from
children.
Use only soapy water to clean the airbag or the backpack. Do not
use harsh cleaning agents like bleach or OxiCleaner. Do not wash
in a washing machine. Protect the suction and release valve from
water and other liquids.
Attention: after cleaning make sure that the system is completely
dry before use – or you risk freezing the components which will
not operate as intended.
