3. Unit description and Parts

Please unfold picture page
1) Puncture unit
2) Airbags
3) Airbags compartment
4) Suction and release unit
5) Release valve
6) Plastic flap
7) Brass quick coupler
8) Handle plate
9) Chest strap
10) Waist belt
11) Leg strap
22
12) Cartridge
13) Cartridge cap
14) Activation handle
15) Pin
4. Initial Operation
4.1 Initial operation and practice release
The uncompromising functioning and the personal handling by
the user of the ABS Avalanche Airbag System are critical. The
handling is straightforward but must be done with care and
according to the steps outlined below:
Step 1
Checking the cartridge weight
Check the weight of the cartridge without the cartridge cap before
each use. The weight is listed on the bottom or the side of the
cartridge. Tolerance limit +/- 5 grams (0.18 oz). Your retail shop
will exchange any cartridge with a weight that differs more than
the tolerance limit at no charge.
English
A completely full cartridge is
an absolute prerequisite for
the proper functioning of the
ABS Avalanche Airbag.
