Mains power supply
Mains voltage
Mains frequency
Max. power consumption electronics
Inputs
Analog In
I/O-net
PF (PowerFail)
Position feedback actuator
Limit switches
Outputs
Relay (2x)
Manual control
Rotary switch
Housing
Plastic housing with screw-on lid
Dimensions (lxwxh)
Weight (unpacked)
Ambient climate
Operating temperature range
Storage temperature range
Relative humidity
I/O-network
Possibility of communication via the I/O-network. One control computer and a maximum of 31 network modules
may be connected to the I/Onetwork. Each connected network module has a unique address. After an address
has been changed, the network module should always be restarted (power off-on).
Output / input type
Output type
Air inlet position
Input type
Analogue measurement (temp.)
Air inlet position measurement
1-phase: 230Vac (-10%, +6%)
3-phase: 400Vac (-10%, +6%)
50/60 Hz
5W
Voltage- or temperature measuring
Voltage 0-10V, temperature sensor
type S7 (-50°C to 110°C)
I/O-net
Make-contact
Potentiometer 4k7Ω (+/- 20%) or CPS
30Vac / 60Vdc , max 1A
1-phase: 240Vac, max 4A
3-phase: 400Vac, max 4A
Closed – 0 – A – 0 - Open
IP54
300x240x140mm
1-phase: 1,92 kg
3-hpase: 2,28 kg
0°C to +40°C / 32°F to 104°F
–10°C to 50°C / 14°F to 122°F
< 95%, uncondensed
IMS address sequence number
"IMS address".01
"IMS address".01
"IMS address".02
